Tractors > Deutz-Allis > 6260

Deutz-Allis 6260



Deutz-Allis 6260 tractor photo
1986 - 1990
6200 Series
Utility tractor
Series map:
6250
6260
6265
54.0hp
61.0hp
70.0hp
Production
ManufacturerDeutz-Allis
Utility tractor
Built in Germany
Variants
6260utility
6260Fnarrow
6260Llow-profile
DX 3.50similar Deutz-Fahr model
Deutz-Allis 6260 Engine
Deutz 3.1L 3-cyl diesel
Engine details ...
Deutz-Allis 6260 Transmissions
8-speed partially synchronized
16-speed two-speed power shift
Transmission details ...
Deutz-Allis 6260 Power
Engine61 hp
45.5 kW
PTO (claimed)57 hp
42.5 kW
Drawbar (tested)50.22 hp
37.4 kW
PTO (tested)57.09 hp
42.6 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Differential lockmechanical rear
Power steering
ROPS Brakesmechanical disc
Cab Brakeshydraulic disc
Four-post ROPS. StarCab optional.
Photos
No photos of the Deutz-Allis 6260 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
ROPS Fuel20 gal
75.7 L
Cab Fuel12 gal
45.4 L
Hydraulic system4 gal
15.1 L
 7.5 galOptOptional
28.4 L
Hydraulics
Typeopen center
Capacity4 gal
15.1 L
 7.5 galOptOptional
28.4 L
Pressure2538 psi
175.0 bar
Valves1 to 3
Pump flow5291 gpm
20026.4 lpm
Tractor hitch
Rear TypeII
Rear lift (at ends)5291 lbs
2399 kg
Front HitchII
Front lift2205 lbs
1000 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Front PTOindependent
Front PTO Type1000
Dimensions & Tires
2WD Wheelbase79 inches
200 cm
4WD Wheelbase82 inches
208 cm
Weight6018 to 7319 pounds
Front tire7.50-16
2WD Rear tire16.9-30
Full dimensions and tires ...
Deutz-Allis 6260 attachments
front-end loader
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
6260 references literature
6240/6250/6260 published in 1985, by Deutz-Allis
