Deutz-Allis 6260F
| | 1986 - 1990 |
| 6200 Series | | Orchard/Vineyard tractor |
|
| Production |
| Manufacturer: | Deutz-Allis
|
| Type: | Orchard/Vineyard tractor
|
| Deutz-Allis 6260F Power |
| PTO (claimed): | 57 hp
42.5 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Steering: | power
|
| Brakes: | hydraulic drum
|
| Cab: | Two-post mid-mount folding ROPS. Cab optional.
|
| Transmissions: | 8-speed
|
| | 12-speed creeper
|
| | 16-speed
|
| | 24-speed
|
 Transmission details ... |
| Photos |
| No photos of the Deutz-Allis 6260F are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type: | open center
|
| Pressure: | 2538 psi
175.0 bar
|
| Valves: | 1 to 4
|
| Pump flow: | 13.7 gpm
51.9 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Rear lift (at ends): | 4850 lbs
2199 kg
|
| Front lift: | 3130 lbs
1419 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540
|
| | 540/1000*Optional
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 55
|
| Battery volts: | 12
|
| Battery AH: | 110
|
| Page information |
| Last update: | November 21, 2018
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
©2000-2021 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Full dimensions and tires ...
