New Holland TT75

New Holland TT75 tractor photo
2002 - 2008
TT Series
Utility tractor
Manufacturer:New Holland
Type:Utility tractor
New Holland TT75 Power
Engine:74.9 hp
55.9 kW
PTO (claimed):59 hp
44.0 kW
New Holland TT75 Engine
Iveco 3.9L 4-cyl diesel
Fuel tank:23.5 gal
88.9 L
Engine details ...
Chassis:4x2 2WD
 4x4 MFWD 4WD
Final drives:spur gear
Brakes:wet disc
Cab:Two-post ROPS.
Transmission details ...
No photos of the New Holland TT75 are currently available. To submit yours, email it to Photos may only be used with the permission of the original photographer.
Type:open center
Pump flow:8.6 gpm
32.6 lpm
Total flow:15.6 gpm
59.0 lpm
Tractor hitch
Rear Type:II/I
Control:position and draft control
Rear lift:4751 lbs
2155 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540
Engine RPM:540@1967
Dimensions & Tires
2WD Wheelbase:86.2 inches
218 cm
4WD Wheelbase:85 inches
215 cm
Weight:5,470 lbs
2481 kg
Front tire:7.50-16
Rear tire:16.9-30
Full dimensions and tires ...
Charging system:alternator
Charging amps:23
Battery volts:12
Battery AH:100
