Tractors > New Holland > TT55

New Holland TT55



New Holland TT55 tractor photo
2002 - 2008
TT Series
Utility tractor
Series map:
TT55
TT75
55.1hp
74.9hp
Production
ManufacturerNew Holland
Utility tractor
Built in India
New Holland TT55 Engine
Iveco 2.9L 3-cyl diesel
Fuel tank23.5 gal
88.9 L
Engine details ...
New Holland TT55 Transmission
8-speed constant mesh
Transmission details ...
New Holland TT55 Power
Engine55.1 hp
41.1 kW
PTO (claimed)47 hp
35.0 kW
Mechanical
Two- or four-wheel drive
Final drivesspur gear
Differential lockmechanical rear
Steeringmanual
 power (4WD)
Wet disc brakes
Two-post fixed ROPS.
Photos
New Holland TT55 utility tractor.
New Holland TT55 photos...
Hydraulics
Typeopen center
Pump flow8.6 gpm
32.6 lpm
Total flow15.6 gpm
59.0 lpm
Steering flow7 gpm
26.5 lpm
Tractor hitch
Rear TypeII/I
Controlposition and draft control
Rear lift3362 lbs
1525 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Engine RPM540@1967
Dimensions & Tires
2WD Wheelbase80.7 inches
204 cm
4WD Wheelbase79.1 inches
200 cm
Weight4895 lbs
2220 kg
Front tire7.50-16
Rear tire16.9-28
Full dimensions and tires ...
New Holland TT55 attachments
front-end loader
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps23
Battery volts12
Battery AH88
References
TT55 references literature
TT (IR/60009/INT) published in 2008
