New Holland TM190 Tests
|
|
| OCED Tractor Test 2144 | |||
| |||
| OCED Tractor Test 2144 | |
| Diesel 19-speed 4WD November 1, 2003 - April 1, 2004 Link: OCED Tractor Test 2144 file | |
| PTO performance | |
| Max power | 172.1 hp 128.3 kW |
| Fuel use | 9.7 gal/hour 36.7 l/hour |
| Power at rated engine speed | 163.6 hp 122.0 kW |
| Fuel use | 10.1 gal/hour 38.2 l/hour |
| Power at rated PTO speed | 167.4 hp 124.8 kW |
| Fuel use | 10.2 gal/hour 38.6 l/hour |
| Drawbar performance | |
| Max power | 137.6 hp 102.6 kW |
| Fuel use | 10.4 gal/hour 39.4 l/hour |
| Gear 9 used for power test. | |
| Max pull | 17,465 lbs 7922 kg |
| Gear 2 used for pull test. | |
