New Holland TN65
|
|
| Production | |
| Manufacturer | New Holland |
| Utility tractor | |
| Built in Jesi, Italy | |
| New Holland TN65 Engine | |
| Iveco 2.9L 3-cyl diesel | |
 Engine details ... |
| New Holland TN65 Transmissions | |
| 8-speed gear | |
| 8-speed partially synchronized | |
| 16-speed partially synchronized | |
| 32-speed two-speed power shift | |
 Transmission details ... |
| New Holland TN65 Power | |
| Engine (gross) | 57 hp 42.5 kW |
| Engine (net) | 53 hp 39.5 kW |
| PTO (claimed) | 47 hp 35.0 kW |
| Drawbar (tested) | 46.0 hp 34.3 kW |
| PTO (tested) | 52.8 hp 39.4 kW |
 Performance test details ... | |
| Mechanical | |
| Two- or four-wheel drive | |
| Final drives | planetary |
| Power steering | |
| Differential hydraulic wet disc brakes | |
| Two-post folding ROPS. Cab optional. | |
| Photos | |
 | |
 New Holland TN65 photos... | |
| Capacity | |
| Fuel | 19.5 gal 73.8 L |
| Hydraulic system | 11.1 gal 42.0 L |
| Hydraulics | |
| Type | open center |
| Capacity | 11.1 gal 42.0 L |
| Pressure | 2755 psi 190.0 bar |
| Valves | 1 to 3 |
| Pump flow | 12.4 gpm 46.9 lpm |
| 16.9 gpmOptOptional 64.0 lpm | |
| Steering flow | 7.2 gpm 27.3 lpm |
| 9.2 gpm*With power shuttle transmission option. 34.8 lpm | |
| Tractor hitch | |
| Rear Type | II |
| Rear lift (at 24"/610mm) | 3962 lbs 1797 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | dry disc |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| 2WD ROPS Wheelbase | 81.5 inches 207 cm |
| 2WD Cab Wheelbase | 83.9 inches 213 cm |
| 4WD ROPS Wheelbase | 78.9 inches 200 cm |
| 4WD Cab Wheelbase | 81.3 inches 206 cm |
| 4WD SuperSteer Wheelbase | 83.5 inches 212 cm |
| Weight | 4665 to 5775 pounds |
| Front tire | 7.50-16 |
| 2WD Rear tire | 14.9-28 |
 Full dimensions and tires ... | |
| New Holland TN65 attachments | |
| front-end loader | |
 Attachment details ... |
| TN65 Serial Numbers | |
| 1998 | 1128584 |
| 1999 | 1157784 |
| 2000 | 1184762 |
| 2001 | 1219306 |
| 2002 | 1252974 |
| 2003 | 1287178 |
| 2004 | 1317364 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| ROPS Charging amps | 45 |
| Cab Charging amps | 65 |
| Battery CCA | 730 |
| Battery volts | 12 |
| References | |
 | |
| New Holland TND/TNS Tractors published in 1998 | |
| New Holland TN/TND/TNS Tractors published in 2002 | |
| New! New Holland TND/TNS Tractors 42 to 62 PTO hp published in 1998 | |
| TN55D TN65D TN75D TN55S TN65S TN75S Operator's Manual (86572984) published in 1998 |
