New Holland TN55


New Holland TN55 tractor photo
1999 - 2004
TN Series
Utility tractor
Series:TN55TN65
TN60A
Production
Manufacturer:New Holland
Type:Utility tractor
Factory:Jesi, Italy
Original price:$30,000 (2000 )
Variants
TN55:ROPS
TN55D:cab
TN55S:SuperSteer
New Holland TN55 Power
Engine (gross):53 hp
39.5 kW
Engine (net):50 hp
37.3 kW
PTO (claimed):42 hp
31.3 kW
Drawbar (tested):35.3 hp
26.3 kW
PTO (tested):43.0 hp
32.1 kW
power test details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Final drives:planetary
Steering:power
Brakes:differential hydraulic wet disc
Cab:Two-post folding ROPS. Cab optional.
Transmissions:8-speed gear
 8-speed partially synchronized
 16-speed partially synchronized
 32-speed two-speed power shift
Transmission details ...
Capacity
Fuel:17.3 gal
65.5 L
Hydraulic system:11.1 gal
42.0 L
Hydraulics
Type:open center
Capacity:11.1 gal
42.0 L
Pressure:2755 psi
190.0 bar
Valves:1 or 2
Pump flow:12.4 gpm
46.9 lpm
 16.9 gpm
64.0 lpm *Optional
Steering flow:7.2 gpm
27.3 lpm
 9.2 gpm
34.8 lpm *With power shuttle transmission option.
Tractor hitch
Rear Type:II
Rear lift (at 24"/610mm):3962 lbs
1797 kg
Power Take-off (PTO)
Rear PTO:independent
Clutch:dry disc
Rear RPM:540 (1.375)
Dimensions & Tires
2WD ROPS Wheelbase:81.5 inches
207 cm
4WD ROPS Wheelbase:78.9 inches
200 cm
2WD Cab Wheelbase:83.9 inches
213 cm
4WD Cab Wheelbase:81.3 inches
206 cm
4WD SuperSteer Wheelbase:93.5 inches
237 cm
Weight:4565 to 5675 pounds
Front tire:7.50-16
2WD Rear tire:14.9-28
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
ROPS Charging amps:45
Cab Charging amps:65
Battery CCA:730
Battery volts:12
