Lamborghini 956
| | 1983 - 1996 |
| Row-Crop tractor |
|
Series map:
956
1106
70.8kw
82.0kw
| Production |
| Manufacturer | Lamborghini (a part of SAME)
|
| Row-Crop tractor |
| Lamborghini 956 Power |
| Engine | 95 hp
70.8 kW
|
| Mechanical |
| Two- or four-wheel drive |
| Final drives | planetary
|
| Differential lock | mechanical front and rear
|
| Power steering |
| Hydraulic wet disc brakes |
| Trailer brakes | hydraulic OptOptional
|
| Cab available with air-conditioning. |
| Hydraulics |
| Pump flow | 16.6 gpm
62.8 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Control | position and draft control
|
| Rear lift | 10141 lbs
4599 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | electro-hydraulic wet disc
|
| Rear PTO Type | 540/1000 (1.375)
|
| Electrical |
| Charging system | alternator
|
| ROPS Charging amps | 45
|
| Cab Charging amps | 55
|
| Battery volts | 12
|
| Battery AH | 110
|
| References |
 |
| C956 published in 1988, by Lamborghini |
