SAME Frutteto II 70
|
|
| Production | |
| Manufacturer | SAME |
| Orchard/Vineyard tractor | |
| SAME Frutteto II 70 Engine | |
| SAME 3.0L 3-cyl diesel | |
| Fuel tank | 10.6 gal 40.1 L |
| 18.5 galOptOptional 70.0 L | |
 Engine details ... | |
| SAME Frutteto II 70 Transmissions | |
| 12-speed partially synchronized | |
| 16-speed creeper | |
| 24-speed two-speed power shift | |
| 32-speed creeper | |
 Transmission details ... |
| SAME Frutteto II 70 Power | |
| Engine (gross) | 70 hp 52.2 kW |
| Engine (net) | 67 hp 50.0 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Power steering | |
| Hydraulic wet disc brakes | |
| Trailer brakes | hydraulic |
| Two-post mid-mount folding ROPS. Cab optional with available air-conditioning. | |
| Photos | |
| No photos of the SAME Frutteto II 70 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pump flow | 8.7 gpm 32.9 lpm |
| Tractor hitch | |
| Rear lift | 6615 lbs 3000 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic |
| Rear PTO Type | 540/1000 |
| Front PTO | independent |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| Wheelbase | 76.77 inches 194 cm |
| Weight | 4762 to 5247 pounds |
| Rear tire | 360/70R24 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Frutteto II / Argon F Classic published in 2006, by SAME | |
| Frutteto II published in 2003, by SAME |
