SAME Titan 160
|
|
| Production | |
| Manufacturer | SAME |
| Row-Crop tractor | |
| SAME Titan 160 Engine | |
| SAME 6.0L 6-cyl diesel | |
| Fuel tank | 60.8 gal 230.1 L |
| 95.1 galOptOptional 360.0 L | |
 Engine details ... | |
| SAME Titan 160 Transmission | |
| 27-speed power shift | |
 Transmission details ... |
| SAME Titan 160 Power | |
| Engine | 159 hp 118.6 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | electro-hydraulic front and rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Trailer brakes | hydraulic |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the SAME Titan 160 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pump flow | 15.9 gpm 60.2 lpm |
| Tractor hitch | |
| Rear lift | 15432 lbs 6999 kg |
| 18960 lbsOptOptional 8600 kg | |
| Front lift | 5071 lbs 2300 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic wet disc |
| Rear PTO Type | 540/1000 |
| Front PTO | independent OptOptional |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| Wheelbase | 112.2 inches 284 cm |
| Weight | 12787 lbs 5800 kg |
| Front tire | 16.9R30 |
| Rear tire | 20.8R38 |
 Full dimensions and tires ... | |
| References | |
 | |
| Titan 145-160-190 published in 1996, by SAME |
