SAME Titan 145


SAME Titan 145 tractor photo
1995 - 1998
Titan Series
Row-Crop tractor
Series map:
Titan 145
Titan 160
108.1kw
118.6kw
Production
ManufacturerSAME
Row-Crop tractor
SAME Titan 145 Engine
SAME 6.0L 6-cyl diesel
Fuel tank60.8 gal
230.1 L
 95.1 galOptOptional
360.0 L
Engine details ...
SAME Titan 145 Power
Engine145 hp
108.1 kW
Mechanical
Four-wheel drive
Differential lockelectro-hydraulic front and rear
Power steering
Hydraulic wet disc brakes
Trailer brakeshydraulic
Cab standard with air-conditioning.
Photos
No photos of the SAME Titan 145 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pump flow15.9 gpm
60.2 lpm
Tractor hitch
Rear lift15432 lbs
6999 kg
 18960 lbsOptOptional
8600 kg
Front lift5071 lbs
2300 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000
Front PTOindependent OptOptional
Front PTO Type1000
Dimensions & Tires
Wheelbase112.2 inches
284 cm
Weight12676 lbs
5749 kg
Front tire16.9R30
Rear tire20.8R38
Full dimensions and tires ...
References
Titan 145 references literature
Titan 145-160-190 published in 1996, by SAME
