Yanmar YM165
|
|
| Production | |
| Manufacturer | Yanmar |
| Compact Utility tractor | |
| Original price was $6,500 in 1986 | |
| Variants | |
| YM165 | 2WD |
| YM165D | 4WD |
| Yanmar YM165 Engine | |
| Yanmar 0.7L 2-cyl diesel | |
 Engine details ... |
| Yanmar YM165 Transmission | |
| 6-speed gear | |
 Transmission details ... |
| Yanmar YM165 Power | |
| Engine | 16 hp 11.9 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Final drives | bull gear |
| Differential lock | mechanical rear |
| Manual steering | |
| Mechanical drum brakes | |
| Open operator station. Two-post ROPS available (RB169) | |
| Photos | |
 | |
 Yanmar YM165 photos... | |
| Capacity | |
| Fuel | 4 gal 15.1 L |
| Hydraulic system | 2.5 gal 9.5 L |
| Hydraulics | |
| Type | open center |
| Capacity | 2.5 gal 9.5 L |
| Pressure | 1138 psi 78.5 bar |
| Valves | 1 |
| Pump flow | 3.8 gpm 14.4 lpm |
| Tractor hitch | |
| Rear Type | I |
| Rear lift (at ends) | 772 lbs 350 kg |
| Front Hitch | 530 |
| Power Take-off (PTO) | |
| Rear PTO | transmission |
| Clutch | overrunning mechanical dry disc |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@2540 |
| 770@2540 | |
| Front PTO | independent OptOptional |
| Clutch | electro-magnetic |
| Front PTO Type | pulley |
| Dimensions & Tires | |
| Wheelbase | 48.8 inches 123 cm |
| Weight | 1109 to 1230 pounds |
| Front tire | 4.50-10 |
| 2WD Rear tire | 8/8-16 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 7 |
| Battery volts | 12 |
| Battery AH | 35 |
| References | |
 | |
| 16HP Diesel Tractor published in 1980, by Yanmar | |
| Operation Manual YM165/YM165D (OME1650(1)-8801) published in 1980 |
