International Harvester 743
| Production |
| Manufacturer | International Harvester
|
| Built in Neuss, Germany |
| International Harvester 743 Power |
| Engine (gross) | 72.4 hp
54.0 kW
|
| Engine (net) | 65.7 hp
49.0 kW
|
| PTO (claimed) | 61.7 hp
46.0 kW
|
| Mechanical |
| Two- or four-wheel drive |
| Final drives | planetary
|
| Differential lock | mechanical rear
|
| Power steering |
| Photos |
| No photos of the International Harvester 743 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Pump flow | 7.9 gpm
29.9 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Rear lift | 6834 lbs
3099 kg
|
| Power Take-off (PTO) |
| Rear PTO Type | 540/1000 (1.375)
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 33
|
| Battery volts | 12
|
| References |
 |
| Tracteurs 743 - 745 S - 845 published by International Harvester |
| Operator's Manual 743 XL - 745 XL - 845 XL (1091846) published in 1981 |
| Page information |
 |
| Copyright 2025 TractorData.com® |
| Email me: Peter@TractorData.com |
| TractorData is a family-owned small business located in Minnesota. I have been researching tractor history and providing specifications for free since 1999. |
| Peter Easterlund - owner/author |
| This machine's data modified on October 9, 2025 |
©2000-2025 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
