Deutz-Fahr Intrac 2003
|
|
| Production | |
| Manufacturer | Deutz-Fahr |
| Tool Carrier tractor | |
| Deutz-Fahr Intrac 2003 Engine | |
| Deutz 3.8L 4-cyl diesel | |
| Fuel tank | 23 gal 87.1 L |
 Engine details ... | |
| Deutz-Fahr Intrac 2003 Transmissions | |
| 8-speed | |
| 8-speed synchronized | |
| 12-speed creeper | |
 Transmission details ... |
| Deutz-Fahr Intrac 2003 Power | |
| Engine | 59 hp 44.0 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| 2WD Steering | manual |
| 4WD Steering | power |
| Cab standard. | |
| Photos | |
| No photos of the Deutz-Fahr Intrac 2003 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pump flow | 10.5 gpm 39.7 lpm |
| Tractor hitch | |
| Rear Type | II/I |
| Rear lift | 5291 lbs 2399 kg |
| Front Hitch | I |
| Front lift | 2205 lbs 1000 kg |
| Power Take-off (PTO) | |
| Rear PTO Type | 540/1000 (1.375) |
| Engine RPM | 540@1890 |
| 1000@1875 | |
| Front PTO Type | 1000 (1.375) |
| Engine RPM | 1000@1875 |
| Dimensions & Tires | |
| 4WD Wheelbase | 86.6 inches 219 cm |
| Weight | 6240 to 7606 pounds |
| Front tire | 7.50-18 |
| 4WD Rear tire | 12.4-32 |
 Full dimensions and tires ... | |
| References | |
 | |
| Intrac 2003 published in 1978, by Deutz-Fahr |
