Deutz-Fahr Intrac 2002


Deutz-Fahr Intrac 2002 tractor photo
1972 - 1974
Intrac 2000 Series
Tool Carrier tractor
Series:Intrac 2002Intrac 2003
Production
Manufacturer:Deutz-Fahr
Type:Tool Carrier tractor
Variants
2002A:4WD
Deutz-Fahr Intrac 2002 Power
Engine:50.3 hp
37.5 kW
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
2WD Steering:manual
4WD Steering:power
Transmissions:8-speed synchronized
 12-speed creeper
Transmission details ...
Photos
No photos of the Deutz-Fahr Intrac 2002 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pump flow:7.2 gpm
27.3 lpm
Tractor hitch
Rear Type:II/I
Rear lift:4930 lbs
2236 kg
Front Hitch:I
Front lift:2579 lbs
1169 kg
Power Take-off (PTO)
Rear RPM:540/1000 (1.375)
Engine RPM:2100
Front RPM:1000 (1.375)
Engine RPM:2100
Dimensions & Tires
2WD Wheelbase:84.7 inches
215 cm
4WD Wheelbase:86.6 inches
219 cm
Weight:5372 to 6724 pounds
Front tire:7.50-16
2WD Rear tire:12.4/11-32
Full dimensions and tires ...
