Fiat 850


Fiat 850 tractor photo
1969 - 1975
Utility tractor
Production
ManufacturerFiat
Utility tractor
Fiat 850 Engine
Fiat 4.9L 4-cyl diesel
Fuel tank22.7 gal
85.9 L
Engine details ...
Fiat 850 Transmissions
12-speed partially synchronized
16-speed creeper
Transmission details ...
Fiat 850 Power
Engine85 hp
63.4 kW
Mechanical
Two- or four-wheel drive
Final drivesplanetary
Differential lockmechanical rear
Steeringmanual
Steeringpower OptOptional
Wet disc brakes
Open operator station.
Photos
No photos of the Fiat 850 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pump flow8.9 gpm
33.7 lpm
Tractor hitch
Rear TypeII
Controlposition and draft control
Rear lift6500 lbs
2948 kg
Power Take-off (PTO)
Rear PTOindependent
Rear RPM540/1000 (1.375)
Engine RPM540@1938
1000@2038
Dimensions & Tires
2WD Wheelbase93 inches
236 cm
4WD Wheelbase94.4 inches
239 cm
Weight6835 to 8068 pounds
Front tire7.50-2
2WD Rear tire13.6/12-38
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
850 references literature
850 published in 1971, by Fiat
850 DT published in 1971, by Fiat
