J.I. Case 210-B
|
|
| Production | |
| Manufacturer | J.I. Case |
| Utility tractor | |
| Built in Rock Island, Illinois, USA | |
| Total built | 364 |
| J.I. Case 210-B Engine | |
| J.I. Case 2.1L 4-cyl gasoline | |
| Fuel tank | 13 gal 49.2 L |
 Engine details ... | |
| J.I. Case 210-B Transmissions | |
| 4-speed gear | |
| 12-speed gear | |
| 8-speed mechanical shuttle | |
 Transmission details ... |
| J.I. Case 210-B Power | |
| Drawbar (claimed) | 25 hp 18.6 kW |
| PTO (claimed) | 30 hp 22.4 kW |
| Plows | 2 |
| Mechanical | |
| Two-wheel drive | |
| Open operator station. |
| Photos | |
 | |
 J.I. Case 210-B photos... | |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 533@1750 |
| Dimensions & Tires | |
| Wheelbase | 75.5 inches 191 cm |
| Weight | 2862 lbs 1298 kg |
| Front tire | 5.50-16 |
| Rear tire | 10-24 |
 Full dimensions and tires ... | |
| 210-B Serial Number Location | |
 | |
| Serial number plate on dashboard. |
| Electrical | |
| Ground | positive |
| Charging system | generator |
| Battery volts | 6 |
| Battery AH | 100 |
| References | |
 | |
| Operator's Instruction Manual 200B Series Wheel Tractors (9-462) published in 1958 | |
| J.I. Case presents published in 1957 |
