Zetor 10741
Series map:
9741
10741
90.0hp
101.0hp
| Production |
| Manufacturer | Zetor
|
| Built in Brno, Czechoslovakia |
| Zetor 10741 Power |
| Engine | 101 hp
75.3 kW
|
| PTO (claimed) | 91 hp
67.9 kW
|
| Drawbar (tested) | 72.7 hp
54.2 kW
|
| PTO (tested) | 92.8 hp
69.2 kW
|
 Performance test details ... |
| Mechanical |
| Four-wheel drive |
| Final drives | inboard planetary
|
| Differential lock | electro-pneumatic rear
|
| Power steering |
| Hydraulic wet disc brakes |
| Cab standard with air-conditioning. |
| Hydraulics |
| Type | open center
|
| Pressure | 2700 psi
186.2 bar
|
| Valves | 3
|
| Pump flow | 19 gpm
71.9 lpm
|
| Total flow | 25 gpm
94.6 lpm
|
| Steering flow | 6 gpm
22.7 lpm
|
| Tractor hitch |
| Rear Type | II/I
|
| Rear lift (at ends) | 10800 lbs
4898 kg
|
| Rear lift (at 24"/610mm) | 9300 lbs
4218 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540/1000 (1.375)
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 70
|
| Battery CCA | 800
|
| Battery volts | 12
|
| References |
 |
| Forterra Series Tractors published in 2004, by Zetor |
