Zetor 9741


No photo available
2004 - 2007
Series map:
9741
10741
90.0hp
101.0hp
Production
ManufacturerZetor
Built in Brno, Czechoslovakia
Zetor 9741 Engine
Zetor 4.2L 4-cyl diesel
Fuel tank48 gal
181.7 L
Engine details ...
Zetor 9741 Transmission
24-speed three-speed power shift
Transmission details ...
Zetor 9741 Power
Engine90 hp
67.1 kW
PTO (claimed)81 hp
60.4 kW
Mechanical
Four-wheel drive
Power steering
Hydraulic wet disc brakes
Cab standard with air-conditioning.
Photos
No photos of the Zetor 9741 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pressure2700 psi
186.2 bar
Valves3
Pump flow19 gpm
71.9 lpm
Total flow25 gpm
94.6 lpm
Tractor hitch
Rear TypeII/I
Rear lift (at ends)10800 lbs
4898 kg
Rear lift (at 24"/610mm)9300 lbs
4218 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
Dimensions & Tires
Wheelbase94 inches
238 cm
Weight9100 lbs
4127 kg
Front tire12.4-24
Rear tire16.9-38
Full dimensions and tires ...
Electrical
Charging systemalternator
Charging amps70
Battery CCA800
Battery volts12
