CaseIH DX33
| | 2001 - 2003 |
| DX Series | | Compact Utility tractor |
|
Series map:
D33
DX33
33.0hp
33.0hp
| Production |
| Manufacturer | CaseIH
|
| Compact Utility tractor |
| Variants |
| D33 | gear
|
| DX33 | hydrostatic
|
| TC33 | similar New Holland model
|
| CaseIH DX33 Power |
| Engine (gross) | 33 hp
24.6 kW
|
| PTO (claimed) | 26.9 hp
20.1 kW
|
| Mechanical |
| Four-wheel drive |
| Power steering |
| Wet disc brakes |
| Two-post folding ROPS. Optional canopy, soft cab, and radio. |
| Hydraulics |
| Type | open center
|
| Pump flow | 7.6 gpm
28.8 lpm
|
| Total flow | 12.7 gpm
48.1 lpm
|
| Steering flow | 5.1 gpm
19.3 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Rear lift (at 24"/610mm) | 1635 lbs
741 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540 (1.375)
|
| Mid PTO | independent
|
| Mid PTO Type | 2000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 40
|
| Battery CCA | 420
|
| Battery volts | 12
|
| References |
 |
| DX Series Compact Tractors published in 2003, by CaseIH |
