John Deere 8520T
| | 2002 - 2005 |
| 8020 Series | | Agricultural Crawler tractor |
|
Series map:
8420T
8520T
284.0hp
305.0hp
| Production |
| Manufacturer | John Deere
|
| Agricultural Crawler tractor |
| Built in Waterloo, Iowa, USA |
| John Deere 8520T Power |
| Engine (gross) | 305 hp
227.4 kW
|
| Engine (net) | 295 hp
220.0 kW
|
| Engine (max) | 335 hp
249.8 kW
|
| PTO (claimed) | 255 hp
190.2 kW
|
| Drawbar (tested) | 219.23 hp
163.5 kW
|
| PTO (tested) | 291.67 hp
217.5 kW
|
 Performance test details ... |
| Mechanical |
| Drive | crawler
|
| Steering | electro-hydraulic power
|
| Hydraulic wet disc brakes |
| Cab standard. |
| Capacity |
| Fuel | 130 gal
492.1 L
|
| Hydraulic system | 65 gal
246.0 L
|
| Hydraulics |
| Type | closed center pressure flow compensated (PFC)
|
| Capacity | 65 gal
246.0 L
|
| Pressure | 2900 psi
200.0 bar
|
| Valves | 5
|
| Pump flow | 30 gpm
113.6 lpm
|
| Total flow | 33.5 gpm
126.8 lpm
|
| | 42.5 gpmOptOptional
160.9 lpm
|
| Tractor hitch |
| Rear Type | III/IIIN
|
| Rear lift | 15,180 lbs
6885 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 1000 (1-3/4)
|
| 8520T Serial Numbers |
| Location: | Rear of tractor
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 150
|
| Batteries | 2
|
| Battery CCA | 925
|
| Battery volts | 12
|
| References |
 |
| 8020T/9020T Series published in 2003, by John Deere |
