John Deere 8320T


John Deere 8320T tractor photo
2002 - 2005
8020 Series
Agricultural Crawler tractor
8310T
Series:8220T8320T8420T
8330T
Production
Manufacturer:John Deere
Type:Agricultural Crawler tractor
Factory:Waterloo, Iowa, USA
Variants
8320:wheeled tractor
8320T:crawler
John Deere 8320T Power
Engine (gross):263 hp
196.1 kW
Engine (net):250 hp
186.4 kW
Engine (max):268 hp
199.8 kW
PTO (claimed):215 hp
160.3 kW
Drawbar (tested):177.43 hp
132.3 kW
PTO (tested):235.12 hp
175.3 kW
power test details ...
John Deere 8320T Engine
John Deere 8.1L 6-cyl diesel
Engine details ...
Mechanical
Chassis:crawler
Steering:electro-hydraulic power
Brakes:hydraulic wet disc
Cab:Cab standard.
Transmission:16-speed full power shift
Transmission details ...
Photos
No photos of the John Deere 8320T are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:130 gal
492.1 L
Hydraulic system:65 gal
246.0 L
Hydraulics
Type:closed center pressure flow compensated (PFC)
Capacity:65 gal
246.0 L
Pressure:2900 psi
200.0 bar
Valves:5
Pump flow:30 gpm
113.6 lpm
Total flow:33.5 gpm
126.8 lpm
 42.5 gpm
160.9 lpm (optional)
Tractor hitch
Rear Type:III/IIIN
Rear lift:15,180 lbs
6885 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:1000 (1-3/4)
Dimensions & Tracks
Wheelbase:89 inches
226 cm
 120 inches
304 cm (wide track opt)
Weight:25950 to 26735 pounds
16-inch tracks
Full dimensions and tracks ...
8320T Serial Numbers
Location:Rear of tractor
Electrical
Ground:negative
Charging system:alternator
Charging amps:150
Batteries:2
Battery CCA:925
Battery volts:12
