Tractors > John Deere > 8320T

John Deere 8320T Tests



John Deere 8320T tractor photo
2002 - 2005
8020 Series
Agricultural Crawler tractor
Series map:
8220T
8320T
8420T
233.0hp
263.0hp
284.0hp
OCED Tractor Test 1776
8320T fuel use from test 311
OCED Tractor Test 1776
Diesel 16-speed crawler
April 17 - May 12, 2000
Link: OCED Tractor Test 1776 file
PTO performance
Max power235.12 hp
175.3 kW
Fuel use12.5 gal/hour
47.3 l/hour
Power at rated engine speed206.33 hp
153.9 kW
Fuel use11.8 gal/hour
44.7 l/hour
Drawbar performance
Max power177.43 hp
132.3 kW
Fuel use11.9 gal/hour
45.0 l/hour
Gear 9 used for power test.
Max pull26,656 lbs
12091 kg
Gear 5 used for pull test.
