John Deere 5425


John Deere 5425 tractor photo
2005 - 2008
5025 Series
Utility tractor
Series:532554255525
5085M
Production
Manufacturer:John Deere
Type:Utility tractor
Factory:Augusta, Georgia, USA
Variants
5425:utility
5425N:narrow-profile
John Deere 5425 Power
Engine (gross):81 hp
60.4 kW
PTO (claimed):65 hp
48.5 kW
PTO (tested):67.99 hp
50.7 kW
power test details ...
John Deere 5425 Engine
John Deere 4.5L 4-cyl diesel
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Final drives:inboard planetary
Differential lock:mechanical rear
Steering:power
Brakes:differential hydraulic wet disc
Cab:Open operator station with two-post folding ROPS. Optional isolated flat-platform (IOOS). Cab available with air-conditioning.
Transmissions:9-speed partially synchronized
 12-speed power shuttle
 24-speed two-speed power shift
Transmission details ...
Capacity
Fuel:25 gal
94.6 L (straddle)
 33.5 gal
126.8 L (IOOS/cab)
Hydraulic system:10.3 gal
39.0 L (9-speed)
 11.5 gal
43.5 L (12-speed)
Front hubs:0.74 qts
0.7 L *Each
Front diff.:4.8 qts
4.5 L
Hydraulics
Type:open center
Capacity:10.3 gal
39.0 L (9-speed)
 11.5 gal
43.5 L (12-speed)
Pressure:2828 psi
195.0 bar
Rear valves:1 to 3
Mid valves:0, 2 or 3
Pump flow:18.4 gpm
69.6 lpm
Total flow:25 gpm
94.6 lpm
Steering flow:6.6 gpm
25.0 lpm
Steering press.:1957 psi
134.9 bar
Tractor hitch
Rear Type:II/I
Control:top-link draft sensing
Rear lift (at 24"/610mm):3374 lbs
1530 kg
Power Take-off (PTO)
Rear PTO:independent
Clutch:dry disc
 electro-hydraulic wet disc (24-speed)
Rear RPM:540
 540/540E*Optional
 540/1000*Optional field conversion kit.
Engine RPM:540@2400
540E@1700
Dimensions & Tires
Wheelbase:85.7 inches
217 cm
Weight:5775 to 7385 pounds
Front tire:7.50-16
2WD Rear tire:16.9-30
Full dimensions and tires ...
5425 Serial Numbers
Location:Left side of tractor frame above the front axle.
photo of 5425 serial number

2005:140001
2006:240001
2007:347001
2008:440001

how to read serial numbers...

Electrical
Ground:negative
Charging system:alternator
ROPS Charging amps:70
Cab Charging amps:90
 120*Optional
Battery CCA:750
Battery volts:12
Battery Group:BCI 31
