John Deere 5105
| | 2000 - 2007 |
| 5000 Advantage Series | | Utility tractor |
|
Series map:
5105
5205
45.6hp
53.0hp
| Production |
| Manufacturer | John Deere
|
| Utility tractor |
| Built in Augusta, Georgia, USA |
| John Deere 5105 Power |
| Engine | 45.6 hp
34.0 kW
|
| PTO (claimed) | 40 hp
29.8 kW
|
| | 44 hp (after SN 512000)
32.8 kW
|
| PTO (tested) | 47.56 hp
35.5 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Power steering |
| Differential mechanical wet disc brakes |
| Two-post folding ROPS. |
| Capacity |
| Fuel | 22.4 gal
84.8 L
|
| Hydraulic system | 8.5 gal
32.2 L
|
| Front axle | 4.8 qts
4.5 L
|
| Front hubs | 0.53 qts
0.5 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 8.5 gal
32.2 L
|
| Pressure | 2800 psi
193.1 bar
|
| Valves | 4
|
| Pump flow | 10.9 gpm
41.3 lpm
|
| Total flow | 17.4 gpm
65.9 lpm
|
| Steering flow | 6.5 gpm
24.6 lpm
|
| Steering press. | 1900 psi
131.0 bar
|
| Tractor hitch |
| Rear Type | II/I
|
| Control | top-link draft sensing OptOptional
|
| Rear lift (at 24"/610mm) | 2990 lbs
1356 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 540@2300
|
| 5105 Serial Numbers |
| Location: | On the right side of the 5105 tractor frame, above the front axle.
|
| 2000 | 110001
|
| 2001 | 210001
|
| 2002 | 310001
|
| 2003 | 410001
|
| 2004 | 510001
|
| 2005 | 610001
|
| 2006 | 710001
|
| 2007 | 810001
|
FAQ: How to read a serial number table.
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 40
|
| Battery CCA | 700 (early)
|
| | 950 (late)
|
| Battery volts | 12
|
| Battery Group | 28H
|
| References |
 |
| Grounds Care Equipment Purchasing Guide published in 2000, by John Deere |
| Grounds Care Equipment Purchasing Guide published in 2001, by John Deere |
| Commercial & Consumer Equipment Purchasing Guide published in 2007, by John Deere |
| 5000 Series Value Selling Guide published in 2005, by John Deere |
| Operator's Manual 5105 and 5205 Tractors (OMRE72817) published in 2005 |
| Economy Class published in 1999, by John Deere |
| Advantage Series Tractors published in 2000, by John Deere |
| Commercial & Consumer Equipment Purchase Guide published in 2005, by John Deere |
