John Deere 4120



John Deere 4120 tractor photo
2004 - 2014
4000 Twenty Compact Series
Compact Utility tractor
Series map:
4120
4320
43.1hp
48.1hp
Production
ManufacturerJohn Deere
Compact Utility tractor
Built in Augusta, Georgia, USA
John Deere 4120 Engine
John Deere 2.4L 4-cyl diesel
Engine details ...
John Deere 4120 Transmissions
12-speed
hydrostatic
Transmission details ...
John Deere 4120 Power
Engine43.1 hp
32.1 kW
PTO (claimed)35 hp
26.1 kW
Mechanical
Four-wheel drive
Steeringhydrostatic power
ROPS.
Photos
John Deere 4120
John Deere 4120 photos...
Capacity
Fuel14.5 gal
54.9 L
Hydraulic system10.3 gal
39.0 L
 9.6 gal (eHydro)
36.3 L
Hydraulics
Typeopen center
Capacity10.3 gal
39.0 L
 9.6 gal (eHydro)
36.3 L
Pressure2500 psi
172.4 bar
Pump flow12 gpm
45.4 lpm
Total flow17.1 gpm
64.7 lpm
Steering flow5.1 gpm
19.3 lpm
Tractor hitch
Rear TypeI
Rear lift (at ends)3,130 lbs
1419 kg
Rear lift (at 24"/610mm)2,500 lbs
1134 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540
Mid PTOindependent (optional)
Mid PTO Type2100
Dimensions & Tires
Wheelbase71.5 inches
181 cm
Weight3700 lbs
1678 kg
Front tire8.00-16
Rear tire13.6-28
Full dimensions and tires ...
John Deere 4120 attachments
72" mid-mount mower deck
front-end loader
backhoe
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps75
Battery CCA770
Battery volts12
References
4120 references literature
Commercial & Consumer Equipment Purchasing Guide published in 2007, by John Deere
4000 Series Compact Utility Tractors published in 2009, by John Deere
4000 Series Compact Utility Tractors published in 2011, by John Deere
Commercial & Consumer Equipment Purchase Guide published in 2005, by John Deere
