Belarus 820
| Production |
| Manufacturer: | Belarus
|
| Factory: | Minsk, Belarus
|
| Original price: | $21,000 (1996 )
|
| Belarus 820 Power |
| Engine: | 85 hp
63.4 kW
|
| PTO (claimed): | 74.8 hp
55.8 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Final drives: | spur gear
|
| Differential lock: | mechanical rear
|
| Steering: | power
|
| Brakes: | disc
|
| Transmission: | 18-speed gear
|
 Transmission details ... |
| Capacity |
| Fuel: | 34.3 gal
129.8 L
|
| Hydraulic system: | 5.4 gal
20.4 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 5.4 gal
20.4 L
|
| Pressure: | 2274 psi
156.8 bar
|
| Valves: | 2
|
| Pump flow: | 11.8 gpm
44.7 lpm
|
| Tractor hitch |
| Rear Type: | II
|
| Control: | position and draft control
|
| Rear lift (at ends): | 4400 lbs
1995 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/1000 (1.375)
|
| Engine RPM: | 540@2068
1000@2158
|
| Electrical |
| Charging system: | alternator
|
| Battery volts: | 12
|
| Page information |
| Last update: | February 16, 2019
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
