John Deere 9320T


John Deere 9320T tractor photo
2002 - 2007
9020 Series
Agricultural Crawler tractor
Series map:
9320T
9420T
375.0hp
425.0hp
Production
ManufacturerJohn Deere
Agricultural Crawler tractor
Built in Waterloo, Iowa, USA
Variants
9320wheeled tractor
John Deere 9320T Engine
John Deere 12.5L 6-cyl diesel
Engine details ...
John Deere 9320T Transmissions
18-speed full power shift
24-speed partial power shift
Transmission details ...
John Deere 9320T Power
Engine375 hp
279.6 kW
PTO (claimed)302 hp
225.2 kW
Drawbar (tested)305.74 hp
228.0 kW
PTO (tested)389.14 hp
290.2 kW
Performance test details ...
Mechanical
Drivecrawler
Steeringelectro-hydraulic power
Hydraulic wet disc brakes
Cab standard.
Capacity
Fuel320 gal
1211.2 L
Hydraulic system27 gal
102.2 L
 27.5 gal (with 3-pt)
104.1 L
Hydraulics
Typeclosed center pressure/flow compensated
Capacity27 gal
102.2 L
 27.5 gal (with 3-pt)
104.1 L
Pressure2900 psi
200.0 bar
Valves4 or 5
Pump flow30 gpm
113.6 lpm
Total flow44 gpm (PowrSync)
166.5 lpm
 48 gpm (Powershift)
181.7 lpm
Tractor hitch
Rear TypeIII, IV/IVN
Rear lift13,871 lbs
6291 kg
 14,445 lbsOptOptional
6552 kg
Power Take-off (PTO)
Rear PTOindependent
Rear RPM1000
Dimensions & Tracks
Wheelbase111 inches
281 cm
Weight39000 to 42840 pounds
30-inch tracks
Full dimensions and tracks ...
9320T Serial Numbers
9320T Serial Location
John Deere 9320T serial number location
Serial number plate on the left side of the tractor frame.
Electrical
Groundnegative
Charging systemalternator
Charging amps140
Batteries3
Battery CCA925
Battery volts12
References
9320T references literature
8020T/9020T Series published in 2003, by John Deere
Operator's Manual 9320T, 9420T, 9520T and 9620T (OMAR288229) published in 2006
