Versatile 256
| Production |
| Manufacturer | Versatile
|
| Built in Winnipeg, Manitoba, Canada |
| Original price was $41,000 in 1985 |
| The Versatile 256 is a bi-directional tractor, designed to operate in both directions of travel. The operator console rotates 180-degrees. |
| Versatile 256 Power |
| Engine | 100.6 hp
75.0 kW
|
| PTO (claimed) | 85.8 hp
64.0 kW
|
| Mechanical |
| Four-wheel drive |
| Steering | power
|
| Hydraulic disc brakes |
| Cab standard with 180-degree console rotation. |
| Capacity |
| Fuel | 39 gal
147.6 L
|
| Hydraulic system | 8.5 gal
32.2 L
|
| Hydraulics |
| Type | closed center load sensing
|
| Capacity | 8.5 gal
32.2 L
|
| Pressure | 2800 psi
193.1 bar
|
| Rear valves | 3
|
| Front valves | 2 OptOptional
|
| Pump flow | 23 gpm
87.1 lpm
|
| Steering flow | 5 gpm
18.9 lpm
|
| Tractor hitch |
| Rear Type | II/I OptOptional
|
| Control | position control
|
| Rear lift (at 24"/610mm) | 4400 lbs
1995 kg
|
| Front Hitch | II/I OptOptional
|
| Front lift (at ends) | 3266 lbs
1481 kg
|
| Front lift (at 24"/610mm) | 2000 lbs
907 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | wet disc
|
| Rear PTO Type | 540/1000 (1.375)
|
| Engine RPM | 540@2500
|
| | 1000@2500
|
| Front PTO | optional
|
| Front PTO Type | 540/1000 (1.375)
|
| Electrical |
| Charging system | alternator
|
| Batteries | 2
|
| Battery CCA | 580
|
| Battery volts | 12
|
| References |
 |
| 200 Series published by Versatile |
| 256 published by Versatile |
| Agricultural Operations Sales Manual published in 1983, by Versatile |
