CaseIH 9330
| | 1996 - 1999 |
| 9300 Series | | Four-wheel Drive (4WD) tractor |
|
Series map:
9310
9330
9350
205.0hp
240.0hp
310.0hp
| Production |
| Manufacturer | CaseIH
|
| Four-wheel Drive (4WD) tractor |
| Built in Fargo, North Dakota, USA |
| Original price was $107,000 in 1999 |
| CaseIH 9330 Power |
| Engine (gross) | 240 hp
179.0 kW
|
| PTO (claimed) | 207 hp
154.4 kW
|
| Drawbar (tested) | 185.88 hp
138.6 kW
|
| PTO (tested) | 229.96 hp
171.5 kW
|
 Performance test details ... |
| Mechanical |
| Four-wheel drive |
| Articulated power steering |
| Hydraulic disc brakes |
| Cab standard with air-conditioning. |
| Hydraulics |
| Type | closed center
|
| Pressure | 2900 psi
200.0 bar
|
| Valves | 4
|
| Pump flow | 28 gpm
106.0 lpm
|
| Tractor hitch |
| Rear Type | III
|
| Rear lift (at 24"/610mm) | 12750 lbs
5783 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 1000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 125
|
| Batteries | 2
|
| Battery CCA | 625
|
| Battery volts | 12
|
| References |
 |
| Steiger 9300 Series 4WDs published in 1996, by CaseIH |
| Product Insight: 9300 STEIGER vs. Agcostar 8360 & 8425 published in 1996 |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on May 29, 2021 |
