CaseIH 9230 Tests


CaseIH 9230 tractor photo
1990 - 1995
9200 Series
Four-wheel Drive (4WD) tractor
9130
Series:921092309240
9330
OCED Tractor Test 1649
9230 fuel use from test 87
OCED Tractor Test 1649
Diesel 12-speed 4WD
June 10 - 14, 1991
Link: OCED Tractor Test 1649 file
PTO performance
Max power:218.20 hp
162.7 kW
Fuel use:11.9 gal/hour
45.0 l/hour
Power at rated engine speed:198.63 hp
148.1 kW
Fuel use:11.7 gal/hour
44.3 l/hour
Power at rated PTO speed:207.83 hp
155.0 kW
Fuel use:11.8 gal/hour
44.7 l/hour
Drawbar performance
Max power:177.51 hp
132.4 kW
Fuel use:11.6 gal/hour
43.9 l/hour
Gear 5 used for power test.
Max pull:25,061 lbs
11367 kg
Gear 2 used for pull test.
