CaseIH Vestrum 120


CaseIH Vestrum 120 tractor photo
2020 -
Vestrum Series
Utility tractor
Series map:
Vestrum 110
Vestrum 120
Vestrum 130
108.5hp
118.4hp
128.2hp
Production
ManufacturerCaseIH (a part of CNH)
Utility tractor
Variants
T5.130similar New Holland model
CaseIH Vestrum 120 Engine
FPT 4.5L 4-cyl diesel
Fuel tank47.5 gal
179.8 L
Exhaust fluid (DEF)5 gal
18.9 L
Engine details ...
CaseIH Vestrum 120 Transmissions
continuously-variable transmission
24-speed 8-speed power shift
Transmission details ...
CaseIH Vestrum 120 Power
Engine (gross)118.4 hp
88.3 kW
Engine (max)128.2 hp
95.6 kW
PTO (claimed)102 hp
76.1 kW
Mechanical
Four-wheel drive
Final drivesinboard planetary
Differential lockelectro-hydraulic rear
Power steering
Hydraulic wet disc brakes
Cab standard with air-conditioning.
Photos
No photos of the CaseIH Vestrum 120 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center load-sensing
Pressure2900 psi
200.0 bar
Rear valves4 OptOptional
Mid valves3 OptOptional
Pump flow29.1 gpm
110.1 lpm
Tractor hitch
Rear TypeII
 IIIN OptOptional
Controlelectronic lower-link draft sensing
Rear lift (at 24"/610mm)9259 lbs
4199 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000 (1.375)
Engine RPM540@1969
 540E@1546
 1000@1893
Front PTOindependent OptOptional
Front PTO Type1000 (1.375)
Dimensions & Tires
Wheelbase98 inches
248 cm
Weight12900 lbs
5851 kg
Front tire380/85R24
Rear tire460/85R34
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps200
Battery volts12
References
Vestrum 120 references literature
Vestrum published in 2023, by CaseIH
