Steiger Super Wildcat
|
|
| Production | |
| Manufacturer | Steiger |
| Four-wheel Drive (4WD) tractor | |
| Built in Fargo, North Dakota, USA | |
| Steiger Super Wildcat Engine | |
| Caterpillar 9.4L 8-cyl diesel | |
 Engine details ... |
| Steiger Super Wildcat Power | |
| Engine | 200 hp 149.1 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | planetary |
| Articulated power steering | |
| Hydraulic disc brakes | |
| Cab standard with available air-conditioning. | |
| Capacity | |
| Fuel | 140 gal 529.9 L |
| Hydraulic system | 30 gal 113.6 L |
| Hydraulics | |
| Type | open center |
| Capacity | 30 gal 113.6 L |
| Pump flow | 15 gpm 56.8 lpm |
| Steering flow | 15 gpm 56.8 lpm |
| Tractor hitch | |
| Rear Type | IV OptOptional |
| Rear lift | 8000 lbs 3628 kg |
| Dimensions & Tires | |
| Wheelbase | 120 inches 304 cm |
| Weight | 17000 lbs 7711 kg |
| Front tire | 18.4-30 |
| Rear tire | 18.4-30 |
 Full dimensions and tires ... | |
| Super Wildcat Serial Numbers | |
| 1969 | 8000 |
| 1970 | 8076 |
| 1971 | 8322 |
| 1972 | 8405 |
| 1973 | 8543 |
| 1974 | 8668 |
| Final | 8675 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 55 |
| Battery volts | 12 |
| References | |
 | |
| Red Book 1971 published by Implement & Tractor | |
| All Wheel Drive Agripower published in 1971, by Canadian Co-operative Implements | |
| Steiger Identification Guide: 1969-1998 published by Case IH | |
| Super Wildcat ...wild with "Cat" power! published in 1969, by Steiger |
