Steiger 3300
| | 1963 - 1969 |
| Barn Series | | Four-wheel Drive (4WD) tractor |
|
Series map:
2200
3300
238.0hp
328.0hp
| Production |
| Manufacturer | Steiger
|
| Four-wheel Drive (4WD) tractor |
| Built in Red Lake Falls, Minnesota, USA |
| Steiger 3300 Power |
| Engine | 328 hp
244.6 kW
|
| Mechanical |
| Four-wheel drive |
| Final drives | planetary
|
| Articulated power steering |
| Drum brakes |
| Open operator station. Cab available. |
| Photos |
| No photos of the Steiger 3300 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 165 gal
624.5 L
|
| Hydraulic system | 64 gal
242.2 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 64 gal
242.2 L
|
| Pump flow | 50 gpm
189.2 lpm
|
| Steering flow | 20 gpm
75.7 lpm
|
| References |
 |
| Red 4WD Tractors: 1957-2017 by Lee Klancher |
| Red Book 1969 published by Implement & Tractor |
| Ultimate Tractor Power: Articulated Tractors of the World, Volume 2 by Peter Simpson* |
| Steiger Identification Guide: 1969-1998 published by Case IH |
| All-Wheel Drive Agricultural Tractors published in 1968, by Steiger |
| Extra Heavy-Duty All-Wheel Drive Agricultural Tractors published in 1969, by Steiger |
| *Publication contains known errors. |
