Massey Ferguson 390
| | 1987 - 1997 |
|
| 300 Series | | Utility tractor |
|
Series map:
383
390
390T
76.0hp
79.0hp
92.0hp
| Production |
| Manufacturer | Massey Ferguson
|
| Utility tractor |
| Built in Coventry, England |
| Original price was $32,000 in 1997 |
| Massey Ferguson 390 Power |
| Engine | 79 hp
58.9 kW
|
| PTO (claimed) | 72 hp
53.7 kW
|
| Mechanical |
| Two- or four-wheel drive |
| Power steering |
| Differential wet disc brakes |
| Two-post fixed ROPS. Cab optional with air-conditioning. |
| Capacity |
| Fuel | 28.5 gal
107.9 L
|
| Hydraulic system | 12.5 gal
47.3 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 12.5 gal
47.3 L
|
| Pressure | 3000 psi
206.8 bar
|
| Valves | 2
|
| Pump flow | 9.5 gpm (aux pump)
36.0 lpm
|
| | 4.4 gpm (hitch)
16.7 lpm
|
| Total flow | 13.9 gpm
52.6 lpm
|
| | 16.8 gpmOptOptional
63.6 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Control | position and draft control
|
| Rear lift | 4250 lbs*Capacity through full lift range
1927 kg
|
| Rear lift (at ends) | 5701 lbs (fixed-end)*Capacity with links horizontal
2585 kg
|
| | 6744 lbs (fixed-end with assist ram)*Capacity with links horizontal
3059 kg
|
| | 5410 lbs (wrist-action)*Capacity with links horizontal
2453 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| | live (optional)
|
| Rear RPM | 540 (1.375)
|
| | 540/1000 (1.375)
|
| 390 Serial Location |
 |
| Serial number plate on the right side of the tractor, near the brake pedals. |
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 45
|
| Battery CCA | 420 (2x)
|
| | 540 (1x)
|
| Battery volts | 12
|
| References |
 |
| Loaders - Compact and Agricultural published in 1989, by Massey Ferguson |
| 300 published in 1988, by Massey Ferguson |
| 300 published in 1989, by Massey Ferguson |
| M-F 300 Series published in 1990, by Massey Ferguson |
| 300 Series HILINE Tractor Cab published in 1992, by Massey Ferguson |
| 300 Series published in 1992, by Massey Ferguson |
| MF 300 Series published in 1994, by Massey Ferguson |
| 300 Series Tractors Data Book published in 1992, by Massey Ferguson |
| M-F 300 Series Tractor Workshop Manual (1449 244M1) published in 1991 |
