J.I. Case 301
| | 1956 - 1958 |
| 300 Series | | Row-Crop tractor |
|
Series map:
301
30.0hp*
*Estimated engine power for comparison only.
| Production |
| Manufacturer | J.I. Case
|
| Row-Crop tractor |
| Built in Rock Island, Illinois, USA |
| Total built | 905
|
| Original price | $3,600 (1958)
|
| Variants |
| 300 | diesel utility
|
| 301 | diesel row-crop
|
| 302 | diesel high-crop
|
| 310 | gasoline utility
|
| 311 | gasoline row-crop
|
| 312 | gasoline high-crop
|
| 320 | industrial
|
| J.I. Case 301 Power |
| Drawbar (claimed) | 22 hp
16.4 kW
|
| Belt (claimed) | 27 hp
20.1 kW
|
| Plows | 3
|
| Drawbar (tested) | 26.31 hp
19.6 kW
|
| Belt (tested) | 30.80 hp
23.0 kW
|
 Performance test details ... |
| Mechanical |
| Two-wheel drive |
| Steering | manual
|
| 6-inch disc brakes |
| Open operator station. |
| Photos |
| No photos of the J.I. Case 301 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | Duo-Control
|
| Valves | 1 (optional)
|
| Tractor hitch |
| Type | Case Eagle Hitch
|
| Power Take-off (PTO) |
| Rear PTO | transmission (4-speed)
|
| | live (Tripl-Range)
|
| Rear PTO Type | 540
|
| References |
 |
| New Case "300" published in 1955, by J.I. Case |
