International Harvester 484
| | 1977 - 1982 |
| 84 Series | | Utility tractor |
|
Series map:
384
484
584
40.0hp*
50.0hp
60.0hp
| Production |
| Manufacturer | International Harvester
|
| Utility tractor |
| Built in Doncaster, England |
| Original price was $11,800 in 1984 |
| International Harvester 484 Power |
| Engine | 50 hp
37.3 kW
|
| Drawbar (claimed) | 38 hp
28.3 kW
|
| PTO (claimed) | 42.4 hp
31.6 kW
|
| Drawbar (tested) | 36 hp
26.8 kW
|
| PTO (tested) | 42.42 hp
31.6 kW
|
 Performance test details ... |
| Mechanical |
| Two-wheel drive |
| Power steering |
| Independent hydraulic wet disc brakes |
| Two-post fixed ROPS. Canopy optional. |
| Capacity |
| Fuel | 20 gal
75.7 L
|
| Hydraulic system | 9 gal
34.1 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 9 gal
34.1 L
|
| Valves | 0 to 2
|
| Total flow | 15.4 gpm
58.3 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Control | position and draft control
|
| Rear lift | 3100 lbs
1406 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | hydraulic wet disc
|
| Rear PTO Type | 540
|
| 484 Serial Number Location |
 |
| Serial number plate on the right side of the frame, above the front axle. |
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
| References |
 |
| 1985 Farm Equipment Buyer's Guide published by CaseIH |
| 1979 Buyer's Guide published by International Harvester |
| Buyer's Guide 1981 published by International Harvester |
| International 30 Series Tractors published by International Harvester |
| 84 Series Hi-Performers published in 1978, by International Harvester |
| International Series 84 Utility/Row-Crop Tractors published in 1978, by International Harvester |
| International Series 84 Tractors published in 1983, by International Harvester |
| Agricultural Equipment Reference Catalog published in 1980, by International Harvester |
