Ford TW-10
|
|
| Production | |
| Manufacturer | Ford |
| Row-Crop tractor | |
| Built in Romeo, Michigan, USA | |
| Original price | $36,160 |
| Ford TW-10 Engine | |
| Ford 6.6L 6-cyl diesel | |
 Engine details ... |
| Ford TW-10 Transmissions | |
| 16-speed | |
| 8-speed | |
 Transmission details ... |
| Ford TW-10 Power | |
| Engine (gross) | 127.9 hp 95.4 kW |
| Engine | 123 hp 91.7 kW |
| Drawbar (claimed) | 97.4 hp 72.6 kW |
| PTO (claimed) | 110 hp 82.0 kW |
| Drawbar (tested) | 94.34 hp 70.3 kW |
| PTO (tested) | 110.24 hp 82.2 kW |
 Performance test details ... | |
| Mechanical | |
| Two- or four-wheel drive | |
| Steering | hydrostatic power |
| Differential hydraulic wet discs brakes | |
| Cab optional with available air-conditioning. | |
| Photos | |
| No photos of the Ford TW-10 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 33 gal 124.9 L |
| 25 gal (auxiliary tank) 94.6 L | |
| Hydraulic system | 18.25 gal 69.1 L |
| 19.75 gal (Dual Power) 74.8 L | |
| Hydraulics | |
| Type | open center |
| Capacity | 18.25 gal 69.1 L |
| 19.75 gal (Dual Power) 74.8 L | |
| Pressure | 2500 psi 172.4 bar |
| Pump flow | 16 gpm 60.6 lpm |
| 8 gpm (service pump) 30.3 lpm | |
| Steering flow | 4.2 gpm 15.9 lpm |
| Tractor hitch | |
| Rear Type | II |
| Rear lift (at 24"/610mm) | 6,000 lbs 2721 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 |
| Dimensions & Tires | |
| Wheelbase | 109.7 inches 278 cm |
| 94 inches (short) 238 cm | |
| Weight | 11250 to 12865 pounds |
| Front tire | 10.00-16 |
| Rear tire | 18.4-38 |
 Full dimensions and tires ... | |
| Ford TW-10 attachments | |
| front-end loader | |
 Attachment details ... |
| TW-10 Serial Numbers | |
| Location: | Under right grill panel |
| 1979 | C592200 |
| 1980 | C635700 |
| 1981 | C660700 |
| 1982 | C682200 |
| 1983 | C694500 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Charging system | alternator |
| Charging amps | 72 |
| Battery volts | 12 |
| Battery AH | 128 |
| References | |
 | |
| 9400 Series published in 1991, by AGCO | |
| Farm Loaders published in 1982, by Ford | |
| TW-10, TW-20, TW-30 published by Ford | |
| Operator's Manual TW-10, TW-20, & TW-30 (SE 3967) published in 1978 |
