Tractors > Allis Chalmers > 7080

Allis Chalmers 7080



Allis Chalmers 7080 tractor photo
1975 - 1981
7000 Series
Row-Crop tractor
Series map:
7060
7080
192.0hp
210.0hp
Production
ManufacturerAllis Chalmers
Row-Crop tractor
Built in West Allis, Wisconsin, USA
Original price$54,561
Allis Chalmers 7080 Engine
Allis Chalmers 7.0L 6-cyl diesel
Fuel tank64 gal
242.2 L
Engine details ...
Allis Chalmers 7080 Transmission
20-speed partial power shift
Transmission details ...
Allis Chalmers 7080 Power
Engine210 hp
156.6 kW
Drawbar (claimed)154 hp
114.8 kW
PTO (claimed)181.5 hp
135.3 kW
Drawbar (tested)148.89 hp
111.0 kW
PTO (tested)181.51 hp
135.4 kW
Performance test details ...
Mechanical
Two-wheel drive
Final drivesinboard planetary
Power steering
Differential hydraulic wet disc brakes
Acousta cab standard with heat, air-conditioning optional. Radio and 8-track player optional. Four-post ROPS canopy available.
Photos
Open station (cut-off cab) Allis-Chalmers 7080, left side.
Allis Chalmers 7080 photos...
Hydraulics
Typeclosed center
Valves2 or 3
Pump flow23 gpm
87.1 lpm
Total flow47 gpm
177.9 lpm
Steering flow10 gpm
37.9 lpm
Tractor hitch
Rear Type3/2
Rear lift (at 24"/610mm)6,680 lbs
3030 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000
Dimensions & Tires
Wheelbase106 inches
269 cm
Weight13638 lbs
6186 kg
Front tire14Lx16
Rear tire20.8x38
Full dimensions and tires ...
Allis Chalmers 7080 attachments
front-end loader
Attachment details ...
7080 Serial Numbers
Location:Above PTO shield
19751007
19761572
19772501
19783001
19793268
19803648
19813954

FAQ: How to read a serial number table.
References
7080 references literature
Loaders - picking up where the others leave off published in 1979, by Allis Chalmers
7040/7060/7080 - The Rising Power in Farming published in 1976, by Allis Chalmers
7080/7060/7045/7020 - All Four, Big Power published in 1978, by Allis Chalmers
7080/7060/7045/7020 - The Power Squadron published in 1980, by Allis Chalmers
7080/7060/7045/7020/7010 - The Power Squadron published in 1981, by Allis Chalmers
