Allis Chalmers 190 Transmission

Allis Chalmers 190 tractor photo
1964 - 1972
Row-Crop tractor
Series map:
*Estimated engine power for comparison only.
TransmissionPower Director
Typetwo-speed power shift
Gears8 forward and 2 reverse
Clutchdry disc
Oil capacity32 qts
30.3 L
 38 qts (S/N 23000 and up)
36.0 L
The transmission is controlled by means of the gear shift lever and the Power Director lever. The tractor must be stopped, and clutch used, to select one of four forward gears, or reverse. The Power Director lever has high, low, and neutral positions. The Power Director can be shifted on the move without clutching. Placing the Power Director into neutral causes the tractor to stop while keeping the PTO engaged.
With 15.5-38 rear tires.
190 Power Director two-speed power shift speeds
Shift Pattern
Allis Chalmers 190 transmission controls
