John Deere 2555


John Deere 2555 tractor photo
1987 - 1992
55 Utility Series
Utility tractor
Series map:
2355
2555
2755
64.0hp
77.0hp
88.0hp
Production
ManufacturerJohn Deere
Utility tractor
FactoriesMannheim, Baden-W├╝rttemberg, Germany
 Saltillo, Mexico
Original price was $25,000 in 1992
The John Deere 2555 was available in two versions. The basic model has the collar shift transmission, naturally-aspirated engine, 540 RPM PTO, 2WD, and ROPS. With the TSS transmission the engine was turbocharged, PTO upgraded to 540/1000, and it was possible to add a cab and four-wheel drive.
Variants
Orchardlow-profile
John Deere 2555 Engine
John Deere 3.9L 4-cyl diesel
Fuel tank22.2 gal
84.0 L
Engine details ...
John Deere 2555 Transmissions
8-speed non-synchronized
8-speed partially synchronized
16-speed partial power shift
8-speed power shuttle
Transmission details ...
John Deere 2555 Power
Engine77 hp
57.4 kW
Drawbar (claimed)56 hp
41.8 kW
PTO (claimed)65 hp
48.5 kW
Mechanical
Two- or four-wheel drive
Steeringpower
 hydrostatic power (optional)
Differential hydraulic wet disc brakes
Roll-Gard ROPS. Optional Sound-Gard cab available with TSS transmission.
Photos
No photos of the John Deere 2555 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center
Pressure2320 psi
160.0 bar
Valves1 to 3
Total flow13 gpm
49.2 lpm
 23 gpmOptOptional
87.1 lpm
Tractor hitch
Rear TypeII/I
Rear lift3269 lbs
1482 kg
Front HitchII OptOptional
Front lift3372 lbs
1529 kg
Power Take-off (PTO)
Rear PTOlive (two-stage clutch)
 independent (with TSS)
Rear RPM540 (CST)
 540/1000 (TSS)
Front PTOindependent OptOptional
Front RPM1000
Dimensions & Tires
Wheelbase89.7 inches
227 cm
Weight6218 to 7717 pounds
Front tire7.50-16
Rear tire15.5-38
Full dimensions and tires ...
2555 Serial Numbers
1987600000
1988624800
1989651786
1990685748
1991718711
1992747703

FAQ: How to read a serial number table.
2555 Serial Location
John Deere 2555 serial number location
Serial number plate on the right side of the tractor frame, above the front axle.
Electrical
Groundnegative
Charging systemalternator
Charging amps55
 85 (with cab)
Batteries2
Battery CCA400
Battery volts12
References
2555 references literature
Utility Equipment Purchasing Guide published in 1987, by John Deere
Utility Equipment Purchasing Guide published in 1988, by John Deere
Powerful Pickups published in 1990, by John Deere
Tractors 40 to 85 HP published in 1986, by John Deere
Tractors 40 to 95 HP published in 1988, by John Deere
Task Masters published in 1990, by John Deere
40 to 100 HP Tractors Product Information Handbook published in 1987, by John Deere
40 to 100 HP Tractors Product Information Handbook published in 1988, by John Deere
40 to 100 HP Tractors Product Information Handbook published in 1991, by John Deere
The 1991 Long Green Line Agricultural Equipment Review published by John Deere
