Transmissions overview | |
8-speed non-synchronized | |
8-speed partially synchronized | |
16-speed partial power shift | |
8-speed power shuttle |
Transmission | |
Transmission: | John Deere Collar Shift (CST) |
Type: | non-synchronized |
Gears: | 8 forward and 4 reverse |
Clutch: | dry disc |
Four gears with two forward and one reverse range. |
Transmission | |
Transmission: | John Deere Top-Shaft Synchronized (TSS) |
Type: | partially synchronized |
Gears: | 8 forward and 4 reverse |
Clutch: | dry disc |
Four gears (1-4) with two ranges (I-II) and reverse range. Optional creeper range provides 12 forward and 8 reverse speeds. |
Speeds | |
With 16.9-24 rear tires. | |
![]() |
Transmission | |
Transmission: | John Deere Hi-Lo Top-Shaft Synchronized (TSS) |
Type: | partial power shift |
Gears: | 16 forward and 8 reverse |
Clutch: | dry disc |
Adds a hydraulic high-low power shift to the basic TSS transmission. |
Speeds | |
With 16.9-24 rear tires. | |
![]() |
Transmission | |
Transmission: | John Deere Collar Shift Reverser |
Type: | power shuttle |
Gears: | 8 forward and reverse |
Adds a hydraulic reverse to the CST transmission. |
