John Deere 7810
| | 1997 - 2003 |
| 7010 Series | | Row-Crop tractor |
|
Series map:
7710
7810
155.0hp
175.0hp
| Production |
| Manufacturer | John Deere
|
| Row-Crop tractor |
| Built in Waterloo, Iowa, USA |
| Original price was $80,000 in 1999 |
| John Deere 7810 Power |
| Engine | 175 hp
130.5 kW
|
| PTO (claimed) | 150 hp
111.9 kW
|
| Drawbar (tested) | 139.47 hp
104.0 kW
|
| PTO (tested) | 167.58 hp
125.0 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Final drives | inboard planetary
|
| Differential lock | electro-hydraulic
|
| Power steering |
| Hydraulic wet disc brakes |
| Cab standard. |
| Capacity |
| ROPS Fuel | 71.5 gal
270.6 L
|
| Cab Fuel | 91 gal
344.4 L
|
| Front axle | 15.2 qts
14.4 L
|
| Front hubs | 2 qts
1.9 L
|
| Hydraulics |
| Type | closed center pressure flow compensated (PFC)
|
| Pressure | 2900 psi
200.0 bar
|
| Valves | 2 to 5
|
| SCV flow | 26 gpm
98.4 lpm
|
| Tractor hitch |
| Rear Type | IIIN/II
|
| Rear lift | 8925 lbs
4048 kg
|
| | 10050 lbsOptOptional
4558 kg
|
| Front Hitch | IIIN/II OptOptional
|
| Front lift | 7700 lbs
3492 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | hydraulic wet discs
|
| Rear PTO Type | 540/1000 (1.375)
|
| Engine RPM | 540@2100
|
| | 1000@2100
|
| 7810 Serial Number Location |
 |
| Serial number plate on the right side of the tractor frame, above the front axle. |
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 140
|
| Batteries | 2
|
| Battery CCA | 925
|
| Battery volts | 12
|
| References |
 |
| 7000 TEN Series Tractors and 7405 Advantage Series Tractors Product Information Handbook published in 1998, by John Deere |
| 7000 TEN Series Tractors and 7405 Advantage Series Tractors Product Information Handbook published in 1999, by John Deere |
| New 95- to 150-HP 7000 TEN Series Tractors published in 1996, by John Deere |
| 7000 TEN Series published in 1999, by John Deere |
| New 7000 TEN Series Tractors - Feel The Earth Move published in 1996, by John Deere |
