| | 1971 - 1975 |
| Generation II Series | | Utility tractor |
|
Series map:
2030
2630
68.0hp
78.2hp*
*Estimated engine power for comparison only.
| Transmission options |
| 8-speed |
| 16-speed partial power shift |
| Transmission |
| Transmission | Collar Shift
|
| Gears | 8 forward and 4 reverse
|
| Oil capacity | 40 qts*Transmission oil shared with hydraulics
37.9 L
|
| Standard transmission. Two selector levers. Right lever has four gear selections. Left lever has high and low ranges, plus reverse and park. |
| Speeds |
|
| Transmission |
| Transmission | Collar Shift - Hi/Lo
|
| Type | partial power shift
|
| Gears | 16 forward and 8 reverse
|
| Clutch | dry disc
|
| Oil capacity | 40 qts*Transmission oil shared with hydraulics
37.9 L
|
| Optional Hi-Lo. Standard transmission with additional shift-on-the-move Hi/Lo selector on the steering column. |
| Speeds |
|
| Transmission |
| Transmission | collar shift - reverser
|
| Gears | 8 forward and reverse
|
| Oil capacity | 40 qts*Transmission oil shared with hydraulics
37.9 L
|
| Optional reverser. Similar to standard transmission with additional shift-on-the-move forward/reverse selector on the steering column. Reverse range on left lever is removed. |
