Tractors > John Deere > 5010

John Deere 5010 Tests



John Deere 5010 tractor photo
1963 - 1965
New Generation Series
Standard-tread tractor
Series map:
5010
134.4hp*
*Estimated engine power for comparison only.
Nebraska Tractor Test 828
5010 fuel use from test 828
Nebraska Tractor Test 828
Diesel 8-speed 2WD
October 15 - 20, 1962
Link: Nebraska Tractor Test 828 file
PTO performance
Power at rated engine speed121.12 hp
90.3 kW
Fuel use8.1 gal/hour
30.7 l/hour
Power at rated PTO speed108.67 hp
81.0 kW
Fuel use7.0 gal/hour
26.5 l/hour
Drawbar performance
Max power105.92 hp
79.0 kW
Fuel use8.0 gal/hour
30.3 l/hour
Gear 4 used for power test.
Max pull14174 lbs
6429 kg
Gear 1 used for pull test.
