Allis Chalmers UC



Allis Chalmers UC tractor photo
1933 - 1941
Row-Crop tractor
All-Crop ↑
Series:UC
Production
Manufacturer:Allis Chalmers
Type:Row-Crop tractor
Factory:West Allis, Wisconsin, USA
Total built:4,647 UC
 1,541 UC Cane
The Allis-Chalmers model UC was originally named the All-Crop.
Variants
U:standard
UC:row-crop
Allis Chalmers UC Power
Drawbar (claimed):19 hp
14.2 kW
Belt (claimed):31 hp
23.1 kW
Plows:3
Drawbar (tested):21.14 hp
15.8 kW
Belt (tested):34.09 hp
25.4 kW
Allis Chalmers UC Engines
Allis-Chalmers 4.9L 4-cyl gasoline
Allis-Chalmers 5.2L 4-cyl gasoline
Fuel tank:24 gal
90.8 L
Aux. fuel:1 gal
3.8 L
Engine details ...
Mechanical
Chassis:4x2 2WD
Cab:Open operator station.
Transmissions:3-speed non-synchronized gear
 4-speed non-synchronized gear
Transmission details ...
Photos
Allis Chalmers UC
Allis Chalmers UC photos...
Dimensions & Tires
Wheelbase:87 inches
220 cm
Weight:5815 lbs
2637 kg
Front tire:24x5
Rear tire:42x2
Full dimensions and tires ...
UC Serial Numbers
Location:Rear axle near PTO
1930:UC1
1931:UC39
1932:UC1100
1933:UC1232
1934:UC1294
1935:UC1552
1936:UC2001
1937:UC2771
1938:UC3757
1939:UC4547
1940:UC4770
1941:UC4972
1944:5038
1945:-
1946:-
1947:5068
1948:5268
1949:5526
1950:5644
1951:5806
1952:5939
1953:6143

how to read serial numbers...

Belt Pulley
Diameter:10 inches
25 cm
Width:7.5 inches
19 cm
RPM:1095
Speed:2870 ft/min
874.78 meters/min
