Kubota L47
|
|
| Production | |
| Manufacturer | Kubota |
| Backhoe loader tractor | |
| Original price was $72,521 in 2026 | |
| Kubota L47 Engine | |
| Kubota 2.4L 4-cyl diesel | |
| Fuel tank | 17.7 gal 67.0 L |
 Engine details ... | |
| Kubota L47 Transmission | |
| hydrostatic | |
 Transmission details ... |
| Kubota L47 Power | |
| Engine (gross) | 47.1 hp 35.1 kW |
| PTO (claimed) | 33 hp 24.6 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | mechanical rear |
| Power steering | |
| Wet disc brakes | |
| Four-post ROPS/FOPS. | |
| Photos | |
| No photos of the Kubota L47 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pump flow | 11.5 gpm 43.5 lpm |
| Tractor hitch | |
| Rear Type | I OptOptional |
| Rear lift (at 24"/610mm) | 2756 lbs 1250 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 72.5 inches 184 cm |
| Weight | 7542 lbs 3421 kg |
| Front tire | 27x10.5-15 |
| Rear tire | 15-19.5 |
 Full dimensions and tires ... | |
| Backhoe & Loader | |
| Dig depth | 121 inches 307 cm |
| Dump angle | 44 inches 111 cm |
 Loader/Backhoe details ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| Tractor Loader Backhoe published in 2022, by Kubota |
