Caterpillar 416 II
|
|
| Production | |
| Manufacturer | Caterpillar |
| Backhoe loader tractor | |
| Caterpillar 416 II Engine | |
| Perkins 3.9L 4-cyl diesel | |
 Engine details ... |
| Caterpillar 416 II Transmission | |
| 4-speed power shuttle | |
 Transmission details ... |
| Caterpillar 416 II Power | |
| Engine (gross) | 67 hp 50.0 kW |
| Engine (net) | 62 hp 46.2 kW |
| Mechanical | |
| Drive | 4x2 2WD |
| 4X4 MFWD 4WD | |
| Power steering | |
| Wet disc brakes | |
| Four-post ROPS. Cab optional with available air-conditioning. | |
| Photos | |
| No photos of the Caterpillar 416 II are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 28.0 gal 106.0 L |
| Hydraulic system | 20.9 gal 79.1 L |
| Front axle | 6.8 qts 6.4 L |
| Rear axle | 16.8 qts 15.9 L |
| Hydraulics | |
| Type | closed center |
| Capacity | 20.9 gal 79.1 L |
| Pressure | 2699 psi 186.1 bar |
| Total flow | 28.5 gpm 107.9 lpm |
| Dimensions & Tires | |
| 2WD Wheelbase | 83 inches 210 cm |
| 4WD Wheelbase | 81 inches 205 cm |
| Weight | 13708 to 13973 pounds |
| Front tire | 11L-16 |
| Rear tire | 16.9-24 |
 Full dimensions and tires ... | |
| Backhoe & Loader | |
| Dig depth | 170 inches 431 cm |
 Loader/Backhoe details ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 52 |
| Battery volts | 12 |
| References | |
 | |
| 416 Series II Backhoe Loader published in 1990, by Caterpillar |
