Lawn Tractors > Cub Cadet > 1811

Cub Cadet 1811 - engine

Cub Cadet 1811 lawn tractor photo
1986 - 1989
Garden tractor
Series next:Cub Cadet 1812
Series back:Cub Cadet 1810
more Cub Cadet 1811 specifications...


Engine Detail:

 Kohler M18
 691 cc [42.18ci ]
Bore/Stroke:3.125x2.75 inches [79 x 70 mm]
Power (gross):18 hp [13.4 kW]
Idle RPM:1200-3600
Starter volts:12
Oil capacity:2 qts [1.9 L]
Sparkplug gap:0.25 inches [6.350 mm]
Intake valve clearance:0.004 inches [0.102 mm] (cold)
Exhaust valve clearance:0.012 inches [0.305 mm] (cold)
