Cub Cadet 3185


Cub Cadet 3185 lawn tractor photo
1998
3000 Series
Garden tractor
Production
ManufacturerCub Cadet (a part of MTD)
Garden tractor
Cub Cadet 3185 Engine
18HP Briggs & Stratton 480cc 2-cyl gasoline
Fuel tank5 gal
18.9 L
Engine details ...
Mechanical
Two-wheel drive
Steeringpower
External disk brakes
Open operator station.
Tractor hitch
Rear Type0 (optional)
Power Take-off (PTO)
Front PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase49.5 inches
125 cm
Weight700 lbs
317 kg
Front tire17x6.5-8
Rear tire24x10.5-12
Full dimensions and tires ...
Cub Cadet 3185 attachments
48" mid-mount mower deck
54" mid-mount mower deck
60" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
Charging systemflywheel alternator
Charging amps16
Battery CCA440
Battery volts12
